ข้อมูลจำเพาะ
| Camera | |||||
| Image Sensor | 1/2.8” 2Megapixel Progressive CMOS | ||||
| Max. Resolution | 1920 (H) × 1080 (V) | ||||
| ROM | 128 MB | ||||
| RAM | 128 MB | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s | ||||
| Minimum Illumination | 0.002 Lux@F1.0 | ||||
| S/N Ratio | > 56 dB | ||||
| Illumination Distance | Up to 30 m (98.43 ft) (Warm Light) | ||||
| Illuminator On/Off Control | Auto; Manual | ||||
| Illuminator Number | 2 (Warm Light) | ||||
| Pan/Tilt/Rotation Range | Pan: 0°–360° | ||||
| Tilt: 0°–90° | |||||
| Rotation: 0°–360° | |||||
| Lens | |||||
| Lens Type | Fixed-Focal | ||||
| Mount Type | M12 | ||||
| Focal Length | 3.6 mm | ||||
| Max. Aperture | F1.0 | ||||
| Field of View | Horizontal 85° × Vertical 45° × Diagonal 100° | ||||
| Iris Type | Fixed | ||||
| Close Focus Distance | 1.7 m (5.58 ft) | ||||
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 3.6mm | 53.8m | 21.5m | 10.8m | 5.4m | |
| (176.51 ft) | (70.54 ft) | (35.43 ft) | 17.72 ft) | ||
| Intelligence | |||||
| IVS (Perimeter Protection) | Intrusion, Tripwire (The Two Functions Support the Classification and Accurate Detection of Vehicle and Human). | ||||
| Smart Search | Work Together with Smart NVR to Perform Refine Intelligent Search, Event Extraction and Merging to Event Videos | ||||
| Video | |||||
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only Supported by the Sub Stream) | ||||
| Smart Codec | Smart H.265+/ Smart H.264+ | ||||
| Video Frame Rate | Main Stream: 1920 × 1080 (1 fps-25/30 fps) | ||||
| Sub Stream: 704 × 576 (1 fps-25 fps), 704 × 480 (1 fps-30 fps) | |||||
| *The Values Above are The Max. Frame Rates of Each Stream; For Multiple Streams, The Values Will Be Subjected to The Total Encoding Capacity. | |||||
| Stream Capability | 2 Streams | ||||
| Resolution | 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 ×720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) | ||||
| Bit Rate Control | CBR/VBR | ||||
| Video Bit Rate | H.264: 32 kbps–6144 kbps | ||||
| H.265: 12 kbps–6144 kbps | |||||
| Day/Night | Color/B/W | ||||
| BLC | Yes | ||||
| HLC | Yes | ||||
| WDR | 120 dB | ||||
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual/Regional Custom | ||||
| Gain Control | Auto/Manual | ||||
| Noise Reduction | 3D NR | ||||
| Motion Detection | OFF/ON (4 Areas, Rectangular) | ||||
| Region of Interest(RoI) | Yes (4 Areas) | ||||
| Smart Illumination | Yes | ||||
| Image Rotation | 0°/90°/180°/270° (Supports 90°/270° with 1080p Resolution and Lower) | ||||
| Mirror | Yes | ||||
| Privacy Masking | 4 Areas | ||||
| Audio | |||||
| Built-In MIC | Yes | ||||
| Audio Compression | G.711A; G.711Mu; G.726; PCM | ||||
| Network | |||||
| Network | RJ-45 (10/100 Base-T) | ||||
| SDK and API | Yes | ||||
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P | ||||
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI | ||||
| User/Host | 20 (Total Bandwidth: 48 M) | ||||
| Storage | FTP; SFTP; Micro SD Card (Support Max. 256 GB) | ||||
| Browser | IE; Chrome; Firefox | ||||
| Management Software | Smart PSS Lite; DSS; DMSS | ||||
| Mobile Phone | IOS; Android | ||||
| Cyber Security | Configuration Encryption; Trusted Execution; Digest;security Logs; WSSE; Account Lockout; Syslog; Video Encryption; 802.1x; IP/MAC Filtering; HTTPS; Trusted Upgrade; Trusted Boot; Firmware Encryption; Generation and Importing of X.509 Certification | ||||
| Power | |||||
| Power Supply | 12V DC/PoE (802.3af) | ||||
| Power Consumption | Basic: 2 W (12 VDC); 2.7 W (PoE) Max.(H.265+Intelligence On+WDR+Illuminator Intensity): 6.2 W(12 VDC); 7.4 W(PoE) | ||||
| Environment | |||||
| Operating Conditions | -40°C to +60°C (-40°F to +140°F)/Less Than ≤ 95% RH | ||||
| Operating Humidity | ≤95% | ||||
| Storage Temperature | -40°C to +60°C (-40°F to +140°F) | ||||
| Storage Humidity | ≤95% | ||||
| Protection Grade | IP67 | ||||
| Structure | |||||
| Casing | Metal | ||||
| Product Dimensions | 70.0 mm×70.0 mm×166.2 mm (2.76″×2.76″×6.54″) (L×W×H) | ||||
| Net Weight | 0.47 kg (1.04 lb) | ||||
| Gross Weight | 0.59 kg (1.30 lb) | ||||
