Specification
| System | |
| Main Processor | Industrial-Grade Processor |
| Operating System | Embedded Linux |
| Operating Interface | Web; Local GUI |
| Quick Pick | |
| QuickPick 2.0 AI by Recorder (Number of Channels) | 2 Channel |
| Perimeter Protection | |
| Perimeter Performance AI by Recorder (Number of Channels) | Advanced Mode: 2 Channels, 10 IVS Rules for Each Channel |
| General Mode: 4 Channels, 10 IVS Rules for Each Channel | |
| Face Detection | |
| Face Attributes | 6 Attributes |
| Face Detection Performance of AI by Recorder (Number of Channels) | 2 Channel (Up to 8 Face Images/s Each Channel) |
| Face Recognition | |
| Face Database Capacity | Up to 10 Face Databases with 10,000 Images. |
| Face Recognition Performance of AI by Recorder (Number of Channels) | 2 Channel |
| SMD Plus | |
| SMD Plus by Recorder | 16 Channels: Secondary Filtering for Human and Vehicle, Reducing False Alarms Caused by Leaves, Rain and Lighting Condition Change |
| SMD Plus by Camera | 24 Channels |
| AI Video Quality Analytics | |
| AI Video Quality Analytics by Recorder | 16 Channels: Supports Detecting Brightness Levels, Color Cast, Defocus, Overexposure, Contrast Levels, Black and White |
| Scene Changing | |
| Scene Changing by Recorder | 1 Channel |
| Irregular Black Block Masking | |
| Irregular Black Block Masking by Recorder | 1 Channel |
| Audio and Video | |
| Encoding Capacity | Encode Enhancement Disabled： |
| Main Stream: | |
| Channels 1-2 5M-N@(1 fps–25 fps), Others 5M-N@(1 fps–12 fps); | |
| Channels 1-2 4M-N/1080p@(1 fps–25/30 fps), Others 4M-N/1080p@(1 fps–15 fps); | |
| 1080N/720p/960H/D1/CIF@(1 fps–25/30 fps); | |
| Sub Stream: D1/CIF@(1 fps–15 fps); | |
| Encode Enhancement Enabled： | |
| Main Stream: | |
| 8-Ch 5 MP@(1 fps-12 fps)/5M-N@(1 fps-25 fps), others 5M-N@(1 fps-12 fps); 8-Ch 4M-N/1080p@(1 fps-25 fps), others 4M-N@(1 fps-15 fps)/1080p@(1 fps-12 fps); 1080N/720p/960H/D1/CIF@(1 fps-25/30 fps) | |
| Sub Stream: D1/CIF@(1 fps-15 fps); | |
| It Changes to D1/CIF@(1 fps-7 fps) When Main Stream is 5 MP/5M-N/4M-N/1080p. | |
| *When Encode Enhancement is Enabled, Video Quality Analytics, Scene Changing, Face Recognition, Face Detection, Perimeter Protection and QuickPick 2.0 Cannot be Used. | |
| Video Bit Rate | 32 kbps–6144 kbps |
| Audio Sampling | 8 kHz, 16 bit |
| Audio Bit Rate | 64 kbps |
| Video Output | 1 HDMI, 1 VGA |
| HDMI: 3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 1024, 1280 × 720 | |
| VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 | |
| Multi-Screen Display | When IP Extension Mode Not Enabled: 1/4/8/9/16 |
| When IP Extension Mode Enabled: 1/4/8/9/16/25 | |
| Third-Party Camera Access | Panasonic; Sony; Hanwha; Axis; Arecont; ONVIF |
| Compression Standard | |
| Video Compression | AI Coding; Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio Compression | G.711a; G.711u; PCM |
| Network | |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.) |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 24.06 (Profile T; Profile S; Profile G); CGI; SDK |
| Browser | Chrome; IE; Safari; Edge; Firefox |
| Recording Playback | |
| Record Mode | General; Alarm; Motion Detection; Intelligent; POS |
| Recording Playback | 1/4/9/16 |
| Backup Method | USB Device and Network |
| Playback Mode | Instant Playback; General Playback; Event Playback; Tag Playback; Smart Playback |
| Storage | |
| Disk Group | Yes |
| Intelligent Alarm | Face Detection; Face Recognition; Perimeter Protection; SMD Plus |
| Alarm Linkage | Record; Snapshot (Panoramic); IPC External Alarm Output; Audio; Buzzer; Log; Preset; Email |
| Ports | |
| Audio Input | 1-Channel RCA |
| 16-Channel BNC (Coaxial Audio) | |
| Audio Output | 1-Channel RCA |
| Two-Way Talk | Yes (Share the Same Audio Input With the First Channel) |
| Disk Interface | 2 SATA Port, Each Disk Can Contain Up to 16 TB. This Limit Varies Depending On the Environment Temperature. |
| RS-485 | 1 |
| USB | 2 (1 Front USB 2.0 Port, 1 Rear USB 2.0 Port) |
| HDMI | 1 |
| VGA | 1 |
| Network Port | 1 (10/100/1000 Mbps Ethernet Port, RJ-45) |
| General | |
| Power Supply | 12 VDC, 4 A |
| Power Consumption | <12 W (Without HDD) |
| Net Weight | 1.80 kg (3.97 lb) |
| Gross Weight | 2.86 kg (6.31 lb) |
| Product Dimensions | 375.0 mm × 289.6 mm × 53.0 mm (14.76″ × 11.40″ × 2.09″) (W × D × H) |
| Packaging Dimensions | 427.0 mm × 137.0 mm × 356.0 mm (16.81″ × 5.39″ × 14.02″) (W × D × H) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–90% (RH), Non-Condensing |
| Installation | Desktop |
