Specification
| System | |
| Main Processor | Industrial-Grade Processor |
| Operating System | Embedded Linux |
| Operation Interface | Web, Local GUI |
| AI | |
| AI by Recorder | SMD Plus |
| AI SearchAI by Camera | Face Detection; Face Recognition; Perimeter Protection; SMD Plus; People Counting; Stereo Analysis; Heat Map |
| Perimeter Protection | |
| Perimeter Performance of AI by Camera (Number of Channels) | 6 Channels |
| Face Detection | |
| Face Attributes | Gender; Age Group; Glasses; Expressions; Face Mask; Beard |
| Face Detection Performance of AI by Camera (Number of Channels) | 6 Channels |
| Face Recognition | |
| Face Recognition Performance of AI by Camera (Number of Channels) | 6 Channels |
| SMD Plus | |
| SMD Plus by Recorder | 4 Channels: Secondary Filtering for Human and Motor Vehicle, Reducing False Alarms Caused by Leaves, Rain and Lighting Condition Change |
| SMD Plus by Camera | 6 Channels |
| Audio and Video | |
| Access Channel | 16 Channels |
| Network Bandwidth | AI Disabled: 160 Mbps Incoming, 160 Mbps Recording and 80 Mbps Outgoing AI Enabled: 80 Mbps Incoming, 80 Mbps Recording and 60 Mbps Outgoing |
| Resolution | 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF |
| Decoding Capability | AI Disabled: 1-Channel 12 MP@30 fps; 2-Channel 8 MP@30 fps; 3-Channel 5 MP@30 fps; 4-Channel 4 MP@30 fps; 8-Channel 1080p@30 fps AI Enabled: 1-Channel 12 MP@30 fps; 1-Channel 8 MP@30 fps; 2-Channel 5 MP@30 fps; 3-Channel 4 MP@30 fps; 7-Channel 1080p@30 fps |
| Video Output | 1 HDMI, 1 VGA Simultaneous： HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 Heterogeneous： HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Multi-Screen Display | Main Screen: 1/4/8/9/16 Sub Screen: 1/4/8/9/16 |
| Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha |
| Compression Standard | |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio Compression | G.711a; G.711u; PCM; G726 |
| Network | |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.) |
| Mobile Phone Access | Android; iOS |
| Interoperability | ONVIF(profile T/S/G); CGI; SDK |
| Browser | Chrome; IE; Safari; Edge; Firefox |
| Record Playback | |
| Multi-Channel Playback | Up to 16 Channels for Playback |
| Record Mode | General, Motion Detection; Intelligent; Alarm |
| Backup Method | USB Storage Device |
| Playback Mode | Instant Playback, General Playback, Event Playback, Tag Playback, Smart Playback |
| Storage | |
| Disk Group | Yes |
| Alarm | |
| General Alarm | Motion Detection, Privacy Masking, Video Loss, Scene Changing, PIR Alarm, IPC External Alarm |
| Anomaly Alarm | Camera Disconnection, Storage Error, Disk Full, IP Conflict, MAC Conflict, Login Locked, and Cybersecurity Exception |
| Intelligent Alarm | Face Detection, Perimeter Protection (Intrusion and Tripwire), IVS, People Counting, Heat Map, and SMD Alarms |
| Alarm Linkage | Recording, Snapshot, Audio, Buzzer, Log, Preset, and Email |
| Port | |
| Audio Input | 1 × RCA Input |
| Audio Output | 1 × RCA Output |
| HDD | 2 SATA III Ports, Up to 20 TB for a Single HDD. The Maximum HDD Capacity Varies With Environment Temperature |
| Alarm Input | 4 |
| Alarm Output | 2 |
| USB | 2 (1 × Front USB2.0; 1 × Back USB2.0) |
| HDMI | 1 (Supports Up to 4K Resolution Output) |
| VGA | 1 |
| Network | 1 (10/100/1000 Mbps Ethernet Port, RJ-45) |
| PoE Port | 16 Ports, 10/100 Mbps, IEEE 802.3 af/at |
| General Parameter | |
| Power Supply | |
| Power Consumption | |
| Net Weight | |
| Gross Weight | |
| Product Dimensions | |
| Package Dimensions | |
| Operating Conditions | -10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Conditions | -20 °C to +60 °C (-4 °F to 140 °F) |
| Operating Humidity | 10%–93% (RH), Non-Condensing |
| Installation | Rack or Desktop |
